American Marconi Wireless News - Tocvan Announces Initial Findings From Drone Magnetic Survey At Gran Pilar Gold-Silver Project: Discovery Of Structural Complex In South Block Aligns With Permitted Drill Targets

The drone magnetic survey, covering approximately 224-line kilometers, was designed to map subsurface geological structures and potential mineralization zones across the expansive Gran Pilar property. Key findings include:

• Identification of a Structural Complex: A prominent structural corridor, characterized by intersecting fault zones across the South Block. This complex extends over a 2.0 by 2.5-kilometer area and exhibits magnetic signatures indicative of magmatic activity potentially tied to mineralization.

• Correlation with Surface Geochemistry: The newly identified structures align closely with previously reported surface rock and soil samples showing elevated gold and silver values, including assays up to 21.2 g/t Au and >2,000 g/t Ag from earlier sampling programs. This correlation suggests the potential for deeper-seated mineralization, enhancing the prospectivity of the area for epithermal gold-silver deposits.

• Expansion of Target Areas: The survey data has refined existing targets and generated several new ones, including extensions to the known Placer Corridor in the South Block, where placer gold mining has historically occurred. There remain several geophysical anomalies to the east and southeast that have not been mapped or sampled.

Video Link Here: Magnetics Update

"We are thrilled with the early outcomes of this drone magnetic survey, which not only validates our geological model but also uncovers exciting new opportunities in the underexplored South Block," said Brodie Sutherland, CEO of Tocvan. "The strong alignment between the magnetic anomalies and our surface geochemistry data underscores the potential for significant discoveries at Gran Pilar. This positions us well to advance our exploration efforts and move closer to realizing the project's full value for our shareholders."

Figures 1 & 2. Upper, First Vertical Derivative (1VD) map of magnetic data with geochemistry. The magnetics are filtered to show near to surface anomalies with major faults and structures associated with lows (blues). Magnetic highs (violet) are associated with magnetite-rich areas tied to magmatic activity (heat drivers for mineralization). The map outlines a 2x2.5 km prospective area. Lower, Total Magnetic Field Reduced to Pole (TMI-RTP) map with geochemistry. A large magnetic high (violet) lies in the centre of the area and correlates to anomalous gold and silver values that potential signals a magmatic centre or heat driving source underneath. The surrounding lows are associated with structural features and alteration connected to epithermal mineralization.

The Company is currently processing the full dataset as additional data is acquired for the North Block and integrating it with existing geophysical, geological, and geochemical information to prioritize drill targets. Surface sampling is underway, with drilling and trenching expected to commence shortly. Tocvan remains committed to a systematic approach to exploration, leveraging advanced technologies to minimize environmental impact while maximizing discovery potential.

Tocvan remains well-positioned with a strong balance sheet and a dedicated team of local experts to execute this program efficiently. Work planned will be conducted on 100% controlled ground. The Company will provide updates as results become available.

100% CONTROLLED PRIORITY TARGETS FOR TRENCHING & DRILLING

1. South Block Main Zone Expansion

   1. Follow-up on 2025 Drill Success

      1. 19.4 g/t Au over 3.1 meters within 106.6 meters of 0.6 g/t Au (February 25, 2025 News Release)

      2. 5.4 g/t Au over 6.1 meters within 41.2 meters of 1.0 g/t Au (May 7, 2025 News Release)

      3. 136 g/t Ag over 10.7 meters within 42.7 meters of 41 g/t Ag (June 25, 2025 News Release)

2. South Block (November 12, 2024 News Release)

   1. Placer Corridor (900-meter strike length)

      1. Soil samples up to 21.2 g/t Au and >2,000 g/t

   2. Placer Source Area

      1. Soil samples up to 2.4 g/t Au and 22 g/t Ag

      2. Rock samples up to 7.3 g/t Au and 389 g/t Ag

3. North Block

   1. North Alteration Zone (3.2 km by 1.5 km area)

      1. 2-meter chip sample, 5.6 g/t Au and 106 g/t Ag (October 19, 2023 News Release)

      2. Historic mine working sample, 3.2 g/t Au and 1,225 g/t Ag (March 8, 2024 News Release)

Figure 3. Gran Pilar Project Overview, > 22km² of prospective ground with two primary targets: South Block, the direct extension and expansion of the historic Main Zone defined by an expanding vein field of untested drill targets; North Block a 3.2-km by 1.5-km pyrite and clay alteration zone that coincides with high-grade gold-silver, the area remains largely untested

Gran Pilar Drill Highlights:

• 2025 Diamond Drilling Highlights include:

  • 83.5m @ 1.3 g/t Au, including 9.7m @ 10.3 g/t Au (March 11, 2025 News Release)

  • 97.4m @ 0.7 g/t Au, including 36.3m @ 1.6 g/t Au (March 19, 2025 News Release)

  • 64.9m @ 1.2 g/t Au, including 3.0m @ 21.6 g/t Au and 209 g/t Ag (March 26, 2025 News Release)

  • 46.9m @ 0.5 g/t Au, including 2.6m @ 7.2 g/t Au and 80 g/t Ag (April 16, 2025 News Release)

• 2025 RC Drilling Highlights include:

  • 106.8m @ 0.6 g/t Au, including 3.1m @ 19.4 g/t Au (February 25, 2025 News Release)

  • 41.2m @ 1.0 g/t Au, including 6.1m @ 5.4 g/t Au (May 7, 2025 News Release)

• 2024 RC Drilling Highlights include (all lengths are drilled thicknesses):

  • 42.7m @ 1.0 g/t Au, including 3.1m @ 10.9 g/t Au

  • 56.4m @ 1.0 g/t Au, including 3.1m @ 14.7 g/t Au

  • 16.8m @ 0.8 g/t Au and 19 g/t Ag

• 2022 Phase III Diamond Drilling Highlights include (all lengths are drilled thicknesses):

  • 116.9m @ 1.2 g/t Au, including 10.2m @ 12 g/t Au and 23 g/t Ag

  • 108.9m @ 0.8 g/t Au, including 9.4m @ 7.6 g/t Au and 5 g/t Ag

  • 63.4m @ 0.6 g/t Au and 11 g/t Ag, including 29.9m @ 0.9 g/t Au and 18 g/t Ag

• 2021 Phase II RC Drilling Highlights include (all lengths are drilled thicknesses):

  • 39.7m @ 1.0 g/t Au, including 1.5m @ 14.6 g/t Au

  • 47.7m @ 0.7 g/t Au including 3m @ 5.6 g/t Au and 22 g/t Ag

  • 29m @ 0.7 g/t Au

  • 35.1m @ 0.7 g/t Au

• 2020 Phase I RC Drilling Highlights include (all lengths are drilled thicknesses):

  • 94.6m @ 1.6 g/t Au, including 9.2m @ 10.8 g/t Au and 38 g/t Ag;

  • 41.2m @ 1.1 g/t Au, including 3.1m @ 6.0 g/t Au and 12 g/t Ag ;

  • 24.4m @ 2.5 g/t Au and 73 g/t Ag, including 1.5m @ 33.4 g/t Au and 1,090 g/t Ag

• 15,000m of Historic Core & RC drilling. Highlights include:

  • 61.0m @ 0.8 g/t Au

  • 21.0m @ 38.3 g/t Au and 38 g/t Ag

  • 13.0m @ 9.6 g/t Au

  • 9.0m @ 10.2 g/t Au and 46 g/t Ag

Pilar Bulk Sample Summary:

• 62% Recovery of Gold Achieved Over 46-day Leaching Period

• Head Grade Calculated at 1.9 g/t Au and 7 g/t Ag; Extracted Grade Calculated at 1.2 g/t Au and 3 g/t Ag

• Bulk Sample Only Included Coarse Fraction of Material (+3/4" to +1/8")

• Fine Fraction (-1/8") Indicates Rapid Recovery with Agitated Leach

  • Agitated Bottle Roll Test Returned Rapid and High Recovery Results: 80% Recovery of Gold and 94% Recovery of Silver after Rapid 24-hour Retention Time

Additional Metallurgical Studies:

• Gravity Recovery with Agitated Leach Results of Five Composite Samples Returned

  • 95 to 99% Recovery of Gold

  • 73 to 97% Recovery of Silver

  • Includes the Recovery of 99% Au and 73% Ag from Drill Core Composite at 120-meter depth.

About Tocvan Ventures Corp.

Tocvan Ventures Corp. is a dynamic exploration and near-term producer advancing high-potential gold and silver projects in the mine-friendly jurisdiction of Sonora, Mexico. At its flagship Gran Pilar Gold-Silver Project, Tocvan holds a 100% interest in over 21 km² of prospective ground, bolstered by the pivotal 2023 land acquisition that provides ample space for scalable mine infrastructure, including a planned 50,000-tonne pilot production facility. The Company also maintains a 51% interest in a 1 km² joint venture area with Colibri Resources, further expanding its footprint. Recent exploration successes, including near surface 3.1 meters at 19.4 g/t Au, underscore Gran Pilar's potential as a premier gold-silver asset. Additionally, Tocvan's 100% owned Picacho Gold-Silver Project, located in the prolific Caborca Trend-home to some of Mexico's largest gold deposits-positions the Company for further growth. With robust metallurgical results (up to 99% gold and 97% silver recovery) and a strategic capital to bolster growth, Tocvan is poised to deliver significant shareholder value in a market buoyed by record-high gold prices. With approximately 64 million shares outstanding, Tocvan is committed to unlocking the full potential of its assets through innovative exploration, strategic development, and investor-focused initiatives.

Quality Assurance / Quality Control

Rock and Drill samples were shipped for sample preparation to ALS Limited in Hermosillo, Sonora, Mexico and for analysis at the ALS laboratory in North Vancouver. The ALS Hermosillo and North Vancouver facilities are ISO 9001 and ISO/IEC 17025 certified. Gold was analyzed using 50-gram nominal weight fire assay with atomic absorption spectroscopy finish. Over limits for gold (>10 g/t), were analyzed using fire assay with a gravimetric finish. Silver and other elements were analyzed using a four-acid digestion with an ICP finish. Over limit analyses for silver (>100 g/t) were re-assayed using an ore-grade four-acid digestion with ICP-AES finish. Control samples comprising certified reference samples and blank samples were systematically inserted into the sample stream and analyzed as part of the Company's robust quality assurance / quality control protocol.

Soil Samples were shipped for sample preparation to ALS Limited in Hermosillo, Sonora, Mexico and for analysis at the ALS laboratory in North Vancouver. The ALS Hermosillo and North Vancouver facilities are ISO 9001 and ISO/IEC 17025 certified. Gold and multi-element analysis of soils was completed by aqua regia digestion and ICP-MS finish using a 50-gram nominal weight. Over limit gold values greater than 1 g/t were re-assayed with a more robust aqua regia digestion ad ICP-MS finish. Over limit analyses for silver (>100 g/t) were re-assayed using an ore-grade four-acid digestion with ICP-AES finish. Control samples comprising blank samples and certified reference materials were systematically inserted into the sample stream and analyzed as part of the Company's robust quality assurance / quality control protocol.

Brodie A. Sutherland, CEO for Tocvan Ventures Corp. and a qualified person ("QP") as defined by Canadian National Instrument 43-101, has reviewed and approved the technical information contained in this release.
